Flexicube Office L30XL Black

To find out more details and the prices of the individual options, download the current product catalogue as a PDF to your email address.

Description

Flexicube Office L30XL Black

Otwarta przestrzeń do pracy

L30 Office to adaptacja nowego kontenera morskiego 40FT HC poszerzonego do 3 m.

Scope of container conversion

to shell condition

NEW SHIPPING CONTAINER (ONE-WAY)

The container conversion is carried out on a new 20ft HC one-way container. The shipping container is made of Corten (weathering) steel with increased resistance to weather conditions. Corten steel was specially designed and developed to minimise corrosion in the very harsh weather conditions found in the marine environment.

CONTAINER STRUCTURAL MODIFICATION

Cutting out and removing sections of the container-sheet walls in order to prepare the structure for the installation of windows and doors. Prefabrication and welding with consistently high-quality welds. Precision and a high standard of finish.

THERMAL INSULATION

Roof and walls spray-insulated with closed-cell polyurethane foam, 80-100 mm thick. Walls additionally insulated with mineral wool, 50 mm thick. Partition heat transfer coefficient (U-value) U 0.16-0.18 [W/(m2•K)]. Floor insulated with closed-cell polyurethane, 50 mm thick. Partition heat transfer coefficient (U-value) U 0.30 [W/(m2•K)]

WINDOWS AND DOORS IN ANTHRACITE

A triple-glazed unit with a heat transfer coefficient of Ug = 0.7 [W/(m2•K)] comes as standard. 5-chamber frame and sash profiles made of class A PVC. Toughened, safety, anti-burglary or solar-control glass can be fitted.

ELECTRICAL INSTALLATION

Flush-mounted, with top-quality fittings (distribution board, sockets, switches).

PLUMBING AND SEWAGE INSTALLATION

Flush-mounted, welded PP, PVC waste pipes. Connections routed through the floor to the outside of the container

WALL AND CEILING FINISHES

Internal steel and timber framework for the walls and ceilings, lined with plasterboard, the surface skim-finished and painted

EXTERIOR PAINTING

The container is painted hydrodynamically with alkyd or polyurethane paint.

Optional equipment

najczęściej wybierane wyposażenie

ŁAZIENKA

Podgrzewacz wody 30L, brodzik 120x80, kabina prysznicowa, bateria prysznicowa termostatyczna, blat łazienkowy (laminat), lustro, umywalka nablatowa, bateria umywalkowa podtynkowa, sedes ze stelażem podtynkowym, grzejnik łazienkowy

KUCHNIA

zabudowa kuchenna IKEA EKESTAD + METOD lub KUNGSBACKA, lodówko-zamrażarka, zlewozmywak jednokomorowy, bateria z wysuwanym wylotem wody.

KLIMIATYZACJA

Klimatyzacja 3,5 kW Haier z funkcją grzania

PODŁOGA

Panele winylowe, listwy przypodłogowe MDF białe 10cm

OŚWIETLENIE

Wewnętrzne i zewnętrzne LED

INFORMACJE DODATKOWE

Budynek ma parametry izolacji na poziomie tradycyjnego domu jednorodzinnego. Nasza izolacja zapewnia komfortowe warunki użytkowania
